Ruijie Reyee RG-ES1 Series User Manual

Hardware Installation and Reference Guide Product Overview
7
PoE overload LED
PoE-max
Off
The overall PoE output does not reach the
maximum power.
Solid green
The overall PoE output reaches the maximum
power.
RJ45 port status LED
Link/Act
(1–24, 25, 26/26F)
Off
The port is not connected.
Solid green
The port is connected at a rate of 10/100/1000
Mbps.
Blinking green
The port is receiving or sending traffic at a rate of
10/100/1000 Mbps.
Solid orange
A 10/100 Mbps link is established on the port.
Blinking orange
The port is receiving and sending data at 10/100
Mbps.
RJ45 PoE status LED
PoE (1–24)
Off
PoE does not supply power.
Solid green
PoE is operational.
1.3 RG-ES110D-P
Technical Specifications
Model
RG-ES110D-P
Ports
Eight 10/100Base-TX auto-sensing Ethernet ports (auto MDI/MDIX), and PoE/PoE+ support
Two 10/100/1000Base-T auto-sensing Ethernet ports (auto MDI/MDIX)
Power Supply
 AC input
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50/60 Hz
Rated current: 1.6 A
 Adapter output
Rated voltage range: 53.5 V DC
Rated current range: 2.24 A
EEE
Port 1–8: supported
Port 9–10: not supported
PoE
Support PoE and PoE+.
