Ruijie RG-S6150-X Series User Manual

Hardware Installation and Reference Guide Appendix
43
7 Appendix
7.1 Connectors and Connection Media
10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX Port
10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX is a port that supports self-adaptation of five
rates, and automatic MDI/MDIX Crossover at these five rates.
10GBASE-T
10GBASE-T complies with IEEE 802.3an standard, and the supported cables and cabling distances are listed
in the following table. 10GBASE-Tport uses four pairs of wires for transmission, all of which must be connected.
The following table shows the connection of the twisted pairs used by the 10GBASE-T port.
Table 7-1 The Twisted Pairs Used by the 10GBASE-T Port
Cable
CAT7 STP
CAT6A STP
CAT6A UTP
CAT6 STP
CAT6 UTP
Description
Cat-7
shielded
twist pairs
Cat-6A
shielded
twist pairs
Cat-6A
unshielded
twist pairs
Cat-6
shielded
twist pairs
Cat-6 unshielded twist
pairs
Model
Class F
ISO/IEC
11801
Class Ea
ISO/IEC 11801 Ed2.1/TIA-568-
C.2
Class E
ISO/IEC TR24750 TSB-155
Max
Transmission
Distance
100 m
100 m
100 m
37 m to 55 m
Cabling
System
Bandwidth
600 MHz
500 MHz
250 MHz
Description
Meet the minimum performance
requirements of 10GBASE-T standard.
Strictly follow TSB-155 standard
requirements to ensure the reliable
application of 10GBASE-T.
Note
The maximum transmission distance will be less than 37m (121.39 ft) when CAT6 UTP unshielded wire is
exposed in severe condition and influenced by external crosstalk.
