Runxin F116Q3 User Manual

MODEL：F67Q/F71Q/F68Q/F69Q/F116Q/F117Q
50
3.6 Trial Running
After installing the multi-functional flow control valve on the resin
tank with the connected pipes, as well as setting up the relevant
parameters, please conduct the trail running as follows:
A. Close inlet/outlet valve B and Valve C, open bypass valve A, clean the
impurity in the pipe, and then close bypass valve A (as Figure 1-3).
B. Add calculated-volume water to the brine tank and adjust the air check
valve. Add solid particle salt to the brine tank then dissolve the salt as
much as possible.
C. Power on. Press and enter Backwash status, 2-lights on, slowly
open the inlet valve B to 1/4 position, making the water flows into the
resin tank; you can hear the sound of air-out from the drain pipeline.
After air totally emptied, then open inlet valve B completely and clean the
impurity in the resin tank until the outlet water is clean. It will take 8～10
minutes to finish the whole process.
D. Press , finish the Backwash status and control valve enter into Brine
& Slow Rinse. 3-lights on, enter into the process of Brine & Slow Rinse.
The air check valve closed when control valve finished brine drawing,
then slow rinse starts to work. It is about 60～65 minutes for whole
process.
E. Press , finish Brine & Slow Rinse, and control valve turns to Fast
Rinse. 4-lights on, and start to fast rinse. After 10～
15 minutes, take
some outlet water for testing: If the water hardness reaches the
requirement, and the content of chloridion in outlet water is almost the
same as the inlet water, then the valve can go to next step: Brine Refill.
F. Press , finish Fast Rinse, and control valve turns to Brine Refill,
5-lights on, the brine tank is being refilled with water to the required level.
It takes about 5～6 minutes, then add solid salt to the brine tank.
G. Press , finish Brine Refill, and control valve turn the status to
Service status and start running.
Note:
 When the control valve enters into the regeneration status, all
programs can be finished automatically according to the setting
time; if you want one of steps to be terminated early, you can press
.
 If water inflows too fast, the media in tank will be damaged. When
water inflows slowly, there is a sound of air emptying from drain
pipeline.
 After changing resin, please empty air in the resin according to
above step C.
 In the process of trial running, please check the water situation in
