English - 14
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently.
1. Press the POWER
P
button on the remote control.
You can also use the POWER
P
button on the TV.
The message Select Language of the OSD. is displayed.
2. Press the  or  button to select the language, then press the ENTER
E
button. The
message Select ‘Home Use’ when installing this TV in your home. is displayed.
3. Press the  or  button to select Store Demo or Home Use, then press the ENTER
E
button. The message Select the
Antenna source to memorize. is displayed.
We recommend setting the TV to Home Use mode for the best picture in your home environment.
Store Demo mode is only intended for use in retail environments. If the unit is accidentally set to Store Demo mode and
you want to return to Home Use (Standard): Press the volume button on the TV. When the volume OSD is displayed,
press and hold the MENU button on the TV for 5 seconds.
4. Press the  or  button to memorize the channels of the selected connection. Press the ENTER
E
button to select Start.
Air: Air antenna signal. / Cable: Cable antenna signal. / Auto: Air and Cable antenna signals.
In Cable mode, you can select the correct signal source among STD, HRC, and IRC by pressing the , ,  or 
button, then press the ENTER
E
button. If you have Digital cable, select the cable system signal source for both Analog
and Digital. Contact your local cable company to identify the type of cable system that exists in your particular area.
5. Press the ENTER
E
button to select Start. The TV will begin memorizing all of the available channels.
To stop the search before it has nished, press the ENTER
E
button with Stop selected.
After all the available channels are stored, it starts to remove scrambled channels. The Auto program menu then
reappears. Press the ENTER
E
button when channel memorization is complete. The message Set the Clock Mode. is
displayed.
6. Press the ENTER
E
button.
Press the  or  button to select Auto, then Press the ENTER
E
button. The message Set to daylight saving time. is
displayed. If you select Manual, Set current date and time is displayed.
7. Press the  or  button to select Off, On or Auto, then press the ENTER
E
button.
8. Press the  or  button to highlight the time zone for your local area. Press the ENTER
E
button. If you have received a
digital signal, the time will be set automatically. If not, see page 22 to set the clock.
9. The connection method to provide the best quality HD is offered. After conrming the method, press the ENTER
E
button.
10. The message Enjoy your watching. is displayed. When you have nished, press the ENTER
E
button.
If you want to reset this feature...
1. Press the MENU button to display the menu. Press the  or  button to select Setup, then press the ENTER
E
button.
2. Press the ENTER
E
button again to select Plug & Play.
The Plug & Play feature is only available in the TV mode.
¦
N
N
N
N
N
N
N
N
N
Plug & Play
Select Language of the OSD.
Menu Language : English
E
Enter

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung LN40B550 and is the answer not in the manual?

Samsung LN40B550 Specifications

General IconGeneral
Audio systemSRS TruSurround HD
RMS rated power20 W
Number of speakers2
Package weight22518 g
Game modeYes
Composite video out1
HDMI ports quantity4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package weight (imperial)49.6 lbs
Response time6 ms
Display diagonal39.9 \
Display brightness- cd/m²
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Contrast ratio (dynamic)70000:1
Product colorBlack
Picture-in-PictureNo
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)254 mm
Width (with stand)983 mm
Height (with stand)676 mm
Weight (with stand)18024 g
Depth (without stand)79 mm
Height (without stand)627 mm
Weight (without stand)14891 g
