CPU Intel Celeron M Optional
Intel Core ‚ processor Duo
Intel Core ‚ processor Solo
Cache memory 2MB / 1MB (Celeron) Optional
Main memory 512MB / Max 2GB, Memory type : DDR2 SODIMM Optional
Main Chipset ATI RC410ME/MD + SB450 Optional
Hard disk drive (HDD) 9.5mmH 2.5" HDD, 60GB Optional
CD drive CD-ROM, RW-Combo, DVD Super Multi Optional
Graphics ATI Radeon Xpress 200M Optional
Sound Realtek ALC262 Codec
Network Interface Modem: V.92 Optional
Wired LAN: Realtek RTL8100C(L) 10/100 Optional
Wireless LAN: 802.11BG Optional
Bluetooth 2.0+EDR Optional
Memory Card Slot Memory Stick, Memory Stick Pro, SD Card, MMC, Highspeed MMC, Optional
xD card Supported
PC Card Slot PCMCIA Type I and, II Compatible Optional
Ports USB 2.0 x 4, Microphone, Headphone, Modem(RJ-11), LAN(RJ-45), Optional
Monitor and TV Out(S-Video), DC Jack, Security Lock Port
Dimensions (mm) 360 x 264.5 x 26.1~ 37.1mm W x D x H
LCD 15.4" WXGA (1280 x 800)
Weight 2.7 ~ 2.74 kg Optional
Battery Lithium-Ion smart battery: 6 Cells
Operation Environment Temperature (storage) : -5 ~ 40?C (operation) : 10 ~ 32? C
Humidity (storage) : 5% ~ 90% (operation) : 20% ~ 80%
Operation Voltage 100 - 240 VAC
Frequency 50 - 60 Hz
Adapter Output Power 60W
Adapter Output Voltage 19.0VDC
A-2
Manual
Item Specification Comment
The system specifications are subject to change without notice. For detailed system specifications, refer to the product
catalog.
The capacity of the hard disk drive with Samsung Recovery Solution will be displayed as less than the specified capacity.
System Specifications
The system specifications will be described below. The system specifications may
differ depending on the derived models.
