S&C Instruction Sheet 695-510 33
Appendix E
Table 9. Accessories
Item Catalog Number
Shotgun clamp stick–for use with separable connectors
6-foot-5½-inch length 9933-150
8-foot-½-inch length 9933-151
Storage bag for shotgun clamp stick. Heavy canvas
6-foot-6-inch length 9933-152
8-foot-6-inch length 9933-153
Pentahead socket for ½-inch drive 9931-074
Motor operator.
①②
Facilitates power operation of load-interrupter switches or fault interrupters. Can be permanently attached
to load-interrupter switches or fault interrupters, or it can be used as a portable motor operator to effect operation of a load-
interrupter switch or fault interrupter from a remote location. Requires user-furnished 120–240-Vac, 50/60-Hz control power
source
38415-A
Portable remote control pendant with a 25-foot (762-cm) cable.
③
Includes OPEN/RESET, CLOSE, and ENABLE pushbuttons,
operator- and isolating-disconnect position-indicating lamps, and a lamp test button. The pendant is fully submersible
TA-3273-25
Portable remote control pendant with a 50-foot (1524 cm) cable.
③
Includes OPEN/RESET, CLOSE, and ENABLE pushbuttons,
operator- and isolating-disconnect position-indicating lamps, and a lamp test button. The pendant is fully submersible
TA-3273-50
Overcurrent control adapter cable.
Required for programming overcurrent
control
For connecting a control to a user-
furnished personal computer in the field
For personal computers having a 25-pin
serial communication port
TA-2366
For personal computers having a 9-pin
serial communication port
TA-2367
For connecting a control to user-
furnished personal computer in the shop
For personal computers having a 25-pin
serial communication port
TA-2368
For personal computers having a 9-pin
serial communication port
TA-2369
① Order portable remote control pendant, one per switchgear assembly
or one for each portable motor operator.
② If switchgear is furnished with optional auxiliary contacts (catalog num-
ber suffix “-S1” through “-S6”), the portable remote control pendant will
show the position of the load-interrupter switch or fault interrupter and the
position of the isolating disconnect.
③ The default color scheme for operator and isolating disconnect
position-indicating lamps is green for OPEN/RESET and red for CLOSED
indcators (these can be reversed).
Appendix F
Table 10. Replacement Parts
Item Catalog Number
600-ampere bushing adapter kit CHA-1976
200-ampere bushing-well adapter kit CHA-1975
Bushing and bushing-well adapter assembly tool
①
CH-2728
① The tool can be used to remove/install 600-ampere bushing adapters; it must be used to remove/install 200-ampere bushing-well adapters.
Table 11. USB Cable Kit
Item Catalog Number
USB cable kit for connecting a personal computer to overcurrent control. Includes driver CD-ROM and installation instructions TA-3153
