–86–
Electrical Adjustments
S0 – Temperature Monitor Indication
–0LM76 (Temp) Monitor Temp. Sensor (Intake) – – –
–1LM76 (Temp) Monitor Temp. Sensor (Inner) – – –
–2Thermistor Monitor Temp. Thermistor (Inner) – – –
–3Thermistor Monitor DAC value – – –
S1 – Pressure Monitor Indication
–0MPXA4114A(Pressure) Monitor Pressure Sensor – – –
S10– RS232C Set
–0Baud rate RS232C Baud rate (0 : 9600 / 1 : 19200) 0 / 1 1 –
–1RTS/CTS Flow Control RS232C RTS/CTS Flow Control (0 : Disable / 1: Enable) 0 / 1 0 –
–2CTS Timeout Second RS232C CTS Timeout 0 ~ 255 0 –
–3Serial Address Individual address in RS–232C chain connection 0 ~ 999 1 –
S20– Logo On/Off
–0Logo On/Off (0 : Menu Operation / 1 : Prohibition) 0 / 1 0 –
S30– Color Shading Correction
–0Correction On/Off (0 : Off / 1 : On) 0 / 1 1 –
S40– Dimmer Control
–0Dimmer On/Off (0 : Menu Operation / 1 : Off) 0 / 1 1 –
–1Dimmer Level (0 : 200W ~ 15 : 250W) 0 ~ 15 15 –
S80– Projector Time
–0Projector Time 0–
S 113 – Reset Frequency Counter
–0Lamp 1 Lamp 1 Total Lighting Time 0 ~ 127 0 –
–1Lamp 2 Lamp 2 Total Lighting Time 0 ~ 127 0 –
–2Lamp 3 Lamp 3 Total Lighting Time 0 ~ 127 0 –
–3Lamp 4 Lamp 4 Total Lighting Time 0 ~ 127 0 –
S 115 – Lamp Go Out
–0Lamp Go Out 0 : Disable / 1 : Enable 0 / 1 0 –
S 120 – RC KEY Disable
–0RC Zoom & Focus Only 0 : Enable / 1 : Disable 0 / 1 0 –
–1RC / KEY All 0 : Enable / 1 : RC Disable / 2 : KEY Disable 0 ~ 2 0 –
–2Process after Power Fail 0 : Not Recover by KEY / 1 : Recover by KEY 0 / 1 0 –
S 121 – RC Select
–0RC Direct Select 0 : Rear & Front / 1 : Front / 2 : Rear / 3 : Disable 0 ~ 3 0
S 140 – Fan Output Level
–0Fan A Min (✽) Fan A Driving Voltage Adj. at TP7611 0 ~ 255 210 –
–1Fan A Max (✽) Fan A Driving Voltage Adj. at TP7611 0 ~ 255 10 –
–2Fan C Min (✽) Fan C Driving Voltage Adj. at TP2661 0 ~ 255 210 –
–3Fan C Max (✽) Fan C Driving Voltage Adj. at TP2661 0 ~ 255 20 –
–4Fan B Min (✽) Fan B Driving Voltage Adj. at TP2671 0 ~ 255 200 –
–5Fan B Max (✽) Fan B Driving Voltage Adj. at TP2671 0 ~ 255 25 –
–6Fan D1 Min (✽) Fan D1 Driving Voltage Adj. at TPFN1 0 ~ 255 110 –
–7Fan D1 Max (✽) Fan D1 Driving Voltage Adj. at TPFN1 0 ~ 255 30 –
–8Fan D2 Min (✽) Fan D2 Driving Voltage Adj. at TPFN2 0 ~ 255 130 –
–9Fan D2 Max (✽) Fan D2 Driving Voltage Adj. at TPFN2 0 ~ 255 40 –
–10Fan D3 Min (✽) Fan D3 Driving Voltage Adj. at TPFN3 0 ~ 255 110 –
–11Fan D3 Max (✽) Fan D3 Driving Voltage Adj. at TPFN3 0 ~ 255 30 –
–12Fan D4 Min (✽) Fan D4 Driving Voltage Adj. at TPFN4 0 ~ 255 130 –
–13Fan D4 Max (✽) Fan D4 Driving Voltage Adj. at TPFN4 0 ~ 255 40 –
S 141 – Fan Output Level
–0Fan Output Level 0 : Max / 1 : Factory / 2 : Auto / 3 : Min 0 ~ 3 2 –
S 150 – Factory Set (Reset)
–0Factory Set Do not touched. Available at No.10 caution : Important! Do not attempt. 0 ~ 10 0 –
S 160 – Shootout
–0Switch 0 : Enable / 1 : Disable 0 / 1 0 –
S 180 – DDC Setting
–0HDCP EDID Data Setting 0 : EDID Data for DVI / 1 : EDID Data for HDCP 0 / 1 1 –
S 200 – CG Full Lamp ( Factory Use – PC Mode )
–0G-SIG Center (✽) DAC Video Center G 0 ~ 255 32 –
–1R-SIG Center (✽) DAC Video Center R 0 ~ 255 32 –
–2B-SIG Center (✽) DAC Video Center B 0 ~ 255 32 –
–3SDIA G DAC PSIGA 0 ~ 255 15 –
–4SDIB G DAC PSIGB 0 ~ 127 214 –
–5SDIA R DAC PSIGA 0 ~ 127 15 –
Group
No.
Data
Range
Initial Value
Function
Item
No.
Item
CAUTION : These initial values are the reference data written from the CPU ROM to the memory IC when the new
memory IC replaced. The adjustment items indicated with “✽” are required to readjust following to the
“Electrical adjustments”. Other items should be used with the initial data value.
● Service Adjustment Data Table
To Next Page
