Sanyo PLC-XF47 User Manual

71
When an input signal is digital from the DVI terminal, refer to the chart below.
Appendix
✔Note:
• Depending on the condition of signals and the type and length of cables, these signals may not be properly
viewed.
• Specifications are subject to change without notice.
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-VGA 640x480 31.470 59.940
D-480p 720x480 31.470 59.880
D-575p 720x575 31.250 50.000
D-SVGA 800x600 37.879 60.320
D-XGA 1024x768 43.363 60.000
D-WXGA 1 1366x768 48.360 60.000
D-WXGA 2 1360x768 47.700 60.000
D-WXGA 3 1376x768 48.360 60.000
D-WXGA 4 1360x768 56.160 72.000
D-WXGA 5 1366x768 46.500 50.000
D-WXGA 6 1280x768 47.776 59.870
D-WXGA 7 1280x768 60.289 74.893
D-WXGA 8 1280x768 68.633 84.837
D-WXGA 9 1280x800 49.600 60.050
D-WXGA 10 1280x800 41.200 50.000
ON-SCREEN
DISPLAY
RESOLUTION H-Freq.(kHz) V-Freq.(Hz)
D-SXGA 1 1280x1024 63.980 60.020
D-SXGA 2 1280x1024 60.276 58.069
D-SXGA+ 1 1400x1050 63.970 60.190
D-SXGA+ 2 1400x1050 65.350 60.120
D-SXGA+ 3 1400x1050 65.120 59.900
D-720p 1280x720 45.000 60.000
D-720p 1280x720 37.500 50.000
D-1035i
1920x1035
(Interlace)
33.750 60.000
D-1080i
1920x1080
(Interlace)
33.750 60.000
1920x1080
(Interlace)
28.125 50.000
D-1080psf/30 1920x1080 33.750 60.000
D-1080psf/25 1920x1080 28.125 50.000
D-1080psf/24 1920x1080 27.000 48.000
Downloaded From projector-manual.com Sanyo Manuals

Sanyo PLC-XF47 Specifications

General

Vertical scan range	48 - 120 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	40 - 600 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	80 °
Keystone correction, horizontal	40 °
I/O ports	Analog (D-sub15), Serial in & Serial out (D-Sub 9 x 2)
Video out	UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA, MAC
Resolution	2359296 pixels
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	581 x 815.5 x 251.5 mm
Power requirements	200-240 V AC 9.7 A Max, 50 / 60 Hz
Connectivity technology	Wired
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Dot clock scanning frequency	230 MHz
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	1700 W

Weight and Dimensions

Weight	36500 g
