■Network Easy Setup Function
Network Easy Setup function by using the SD memory card
1. Outline
This projector provides a function to setup the network automatically by reading the network setting file (PJ_Network.ini)
stored in the top directory of the SD memory card. By using the function, network setup can be done easily.
Setting Procedure
1. Create the network setting file (PJ_Network.ini) with your computer's text editor software. Refer to the item "2. Function de-
tails" below for the format and contents of the network setting file.
2. Put the network setting file into the top directory of the SD memory card.
3. Insert the SD memory card into the projector's card slot.
4. Turn the projector on. The projector loads the setting file information in the SD memory card and applies them to own net-
work setting.
Setting items
Used LAN No. .................... Used LAN No. is specified. Projector is forced to select the LAN No. specified with this item while
the SD memory card is installed.
LAN Setting Items ...........Network settings are specified. The available items are shown in the table below.
LAN No.
LAN1 LAN2 LAN3 LAN4 LAN5 LAN6
Setting items
Type
✔ ✔ ✔ ✔ ✔
--
IP address
✔ ✔ ✔ ✔ ✔
--
Subnet mask
✔ ✔ ✔ ✔ ✔
--
Gateway
✔ ✔ ✔ ✔ ✔
--
DNS server
✔ ✔ ✔ ✔ ✔ ✔
Wireless type -- -- --
✔ ✔
--
Channel No. -- -- --
✔ ✔
--
WEP key index -- -- --
✔ ✔
--
Key code -- -- --
✔ ✔
--
Security -- -- --
✔ ✔
--
Mode -- -- --
✔ ✔
--
SSID -- -- --
✔ ✔
--
WEP key -- -- --
✔ ✔
--
PSK(TKIP) key -- -- --
✔ ✔
--
PSK(AES) key -- -- --
✔ ✔
--
* LAN1 to LAN3 are for the wired LAN settings. LAN4 to LAN6 are for the wireless settings. LAN6 can be setup only the
DNS server address because it is for the wireless simple setting.
2. Function details
2-1 Format of setting file
Format of setting file is specified as follows;
[Setting object] + ":" + [item] + [tab] + [item] + [tab] + [item] + [tab] + [item] + [tab] + .........
* Number of setting items and types are depending on the [Setting object].
