- 51 -
Service Adjustment
Note On White Uniformity Adjustment
If the correction of the Color shading adjustment is neces-
sary, please adjust the "Color shading" by using the "PRO-
JECTOR SERVICE TOOL CD-ROM" software supplied sepa-
rately.
The color shading correction adjustment for this model
should be performed with the whole-gray patterns speci-
fied as below.
4-input patterns:
12.0% gray, 25.0% gray, 50.0% gray, 75.0% gray
The software can be ordered as follows;
PROJECTOR SERVICE TOOL CD-ROM Ver. 4.20
Service Parts No. 610 343 5596
This adjustment must use the service tool.
Adjust the gamma curve correction by using the proper
computer and "PROJECTOR SERVICE TOOL CD-ROM" soft-
ware supplied separately.
7. Gamma Correction adjustment
8. Read/Write of LCD panel gamma data when
Main Board replacing
The gamma adjustment data of each LCD panel has been
adjusted preciously to much each LCD panel characteristics
at factory.
When you replace the Main Board, you need to read out
the gamma data stored in the memory IC on the previous
board and write down the gamma data into the memory
IC on the new board. By this way, the projector is enabled
to reproduce the picture which has the properly adjusted
gamma characteristic.
Use "PROJECTOR SERVICE TOOL CD-ROM" for Read / Write
of the gamma data as follows;
To Next Page
