- 30 -
7
Optical unit removal.
1. Remove the 5 screws-A(T3x8) and remove the Optical unit.
A
Optical unit
A
A
A
A
Mechanical disassemblies
Caution ;
Do not lose these parts. (4 pieces)
(damper and Washer).
