Sanyo PLC-XL51A Service Manual

- 53 -
Service Adjustment Data Table
These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjustment
items indicated with “✻” are required to readjust following to the
“Electrical adjustments”. Other items should be used with the initial
data value.
Group/ Item
Item Name Function Initial Range Note
Group 0 AD Converter (PW190)
0 ADC G-OFFSET PC / Component / SCART 132/127/132 0 - 255
1 ADC R-OFFSET PC / Component / SCART 130/139/128 0 - 255
2 ADC B-OFFSET PC / Component / SCART 148/154/128 0 - 255
3 ADC G-GAIN PC / Component / SCART 50/50/50 0 - 255
4 ADC R-GAIN PC / Component / SCART 40/40/40 0 - 255
5 ADC B-GAIN PC / Component / SCART 40/40/40 0 - 255
6 GRAAFLTR/RBAAFLTR Green (Red and Blue) Anti-Alias Filter 4 / R / R 0 - 7
Composite & S-Video / Component /
PC
*R: Read only value
7
GRNAADWNSMPL /
RBAADWNSMPL
Green (Red and Blue) Anti-Alias
Downsample
0 / R / R 0 - 3
8 GRNAAHF / RBAAHF
Green (Red and Blue) Anti-Alias High
Frequency
3 / R / R 0 - 3
10 SOGTH
PC / Component / SCART
SyncOn Green Threhould
6 / 4 / 4 0 - 15
11 SOGHYSDIS
PC / Component / SCART
Sync On Green Hsysterisis Enable
0 0 - 1
12 HS1TH 4 0 - 7
13 HS0TH 4 0 - 7
100 PreCoast PC Signal 3 0 - 63
101 PostCoast PC Signal 8 0 - 63
120 PreCoast PC Video 480i 7 0 - 63
121 PostCoast PC Video 480i 13 0 - 63
122 PreCoast PC Video 575i 7 0 - 63
123 PostCoast PC Video 575i 13 0 - 63
124 PreCoast PC Video 480p 7 0 - 63
125 PostCoast PC Video 480p 13 0 - 63
126 PreCoast PC Video 575p 7 0 - 63
127 PostCoast PC Video 575p 13 0 - 63
128 PreCoast PC Video 720p 60Hz 7 0 - 63
129 PostCoast PC Video 720p 60Hz 13 0 - 63
130 PreCoast PC Video 720p 50Hz 7 0 - 63
131 PostCoast PC Video 720p 50Hz 13 0 - 63
132 PreCoast PC Video 1080i 60Hz 7 0 - 63
133 PostCoast PC Video 1080i 60Hz 13 0 - 63
134 PreCoast PC Video 1080i 50Hz 7 0 - 63
135 PostCoast PC Video 1080i 50Hz 13 0 - 63
136 PreCoast PC Video 1035i 7 0 - 63
137 PostCoast PC Video 1035i 13 0 - 63
138 PreCoast PC Video 1080p 60Hz 7 0 - 63
139
PostCoast PC Video 1080p
60Hz
13 0 - 63
140 PreCoast PC Video 1080p 50Hz 7 0 - 63
141
PostCoast PC Video 1080p
50Hz
13 0 - 63
142 PreCoast PC Video 1080p 30Hz 7 0 - 63
143
PostCoast PC Video 1080p
30Hz
13 0 - 63
144 PreCoast PC Video 1080p 25Hz 7 0 - 63
145
PostCoast PC Video 1080p
25Hz
13 0 - 63
146 PreCoast PC Video 1080p 24Hz 7 0 - 63
147
PostCoast PC Video 1080p
24Hz
13 0 - 63
150 PreCoast YCbCr 480i 7 0 - 63
151 PostCoast YCbCr 480i 13 0 - 63
152 PreCoast YCbCr 575i 7 0 - 63
153 PostCoast YCbCr 575i 13 0 - 63
154 PreCoast YCbCr 480p 7 0 - 63
155 PostCoast YCbCr 480p 13 0 - 63
156 PreCoast YCbCr 575p 7 0 - 63
157 PostCoast YCbCr 575p 13 0 - 63
158 PreCoast YCbCr 720p 60Hz 7 0 - 63
159 PostCoast YCbCr 720p 60Hz 13 0 - 63
160 PreCoast YCbCr 720p 50Hz 7 0 - 63
161 PostCoast YCbCr 720p 50Hz 13 0 - 63
Service Adjustment
