www.schaerer.comInstallation & commissioning
Operating instructions / V04/01.2012
15/76
SCA Plus Japan
200-220 V 2~ 50/60 Hz 4700-5800 W 2x 25 A 3x 2.5 mm
2
200 V 2~ 50/60 Hz 3900 W 2x 20 A 3x 2.5 mm
2
200-220 V 3~ 50/60 Hz 6900-8500 W 3x 25 A 4x 2.5 mm
2
200 V 3~ 50/60 Hz 7000 W 3x 20 A 4x 2.5 mm
2
Water connection / draining
Conditions
The water supply connection must be made in accordance with the applicable requirements and the re-
gulations of the respective country. If the machine is connected to a newly installed water line, the pipe
and the inlet hose must be thoroughly ushed to prevent particles from entering the machine. The coffee
machine must be connected to an installed drinking water line with a shut-off valve. The machine is con-
nected to the pressure reducing valve on the main water valve (set to 0.3 MPa (3 bar)) using the mounted
pressure hose and the G 3/8" screw connection. If the machine is connected to a drain, the included tem-
perature-resistant drain hose must be connected to the drip tray and the siphon. It must be rmly attached
to the drain and slanted at a downward angle (so that the water can ow downward).
● Always use the new hose set (fresh water/outlet hose) provided with the machine! Do not use
old hose sets.
● Schaerer Ltd. recommends setting the pressure reducing valve to 0.3 MPa (3 bar).
Water supply G 3/8" tube connection (inside thread) with main tap and dirt lter provi-
ded by customer, max. water temperature 30 °C.
Flow speed Min. 2 l/min.
Water pressure
Recommended Maximum
0.1-0.3 MPa (1-3 bar) 0.6 MPa (6 bar)
Water inlet temperature
Minimum Maximum
10°C 30 °C
Water quality The water must be free of contaminants and the chlorine content must
not exceed 100 mg per litre. Do not connect the machine to pure reverse
osmosis water or other aggressive types of water. The carbonate hard-
ness must not exceed 4 – 6°dKH (German carbonate hardness) or 7 –
10°fKH (French carbonate hardness), and the total hardness value must
always be higher than the carbonate hardness. The minimum carbonate
hardness is 4°dKH or 7°fKH. The pH value must be between 6.5 – 7.
Water drainage line Hose at least Ø 19 mm, minimum slope 2 cm/m
Deinstallation and disposal
Contact a qualied customer service representative approved by the manufacturer.
CAUTION!
Risk of machine
damage!
