• Machines tted with a sawdust extractor and
extractor hoods must be connected to the devices
concerned. The type of material used can have a
negative inuence on the dust generated.
• The machine is designed exclusively for the cut-
ting of wood and similar materials.
• The knife must be replaced immediately once it
becomes worn down by 5%.
• If a push stick is not used there may be a risk of
serious danger. The push stick should always be
kept at the machine when not used.
• There is a greater risk of danger when small
workpieces are fed in by hand. Always observe
the manufacturer’s instructions on the use of the
push stick.
• If the safety covers, infeed table or mesh are in-
correctly aligned they could lead to uncontrollable
situations.
• Damaged or soiled workpieces may cause a risk
of danger. Never use metal parts in the machine or
any materials which can fracture or shatter. Risk
of injury!
• To cut long workpieces, always place them on a
mobile table or similar type of supporting equip-
ment. Otherwise there is a risk that you may lose
control over the workpiece.
• The machine is only suitable for planing and thick-
nessing.
• Wear suitable protective clothing when working
with the machine:
- ear protection to prevent damage to your ears,
- a breathing mask to avoid the risk of inhaling
hazardous particles of dust,
- safety gloves to avoid injuries from sharp edges
or knives,
- safety goggles to avoid eye injuries from ying
parts.
• It is imperative that the following situations are
avoided at all times: Premature interruption of the
cutting operation (planing cuts which do not com-
plete the entire length of the workpiece; planing of
uneven pieces of wood which do not lie at on the
infeed table).
• Important! If the primary mains connection is in a
poor condition there is a risk of short-circuits when
the machine is switched on. This may also affect
other functions (e.g. the lighting up of indicator
lamps). Should there be any faults in the primary
mains connection, please contact your local elec-
tricity supplier to advice and information.
Residual risks
Even when the machine is used as prescribed it is
still impossible to eliminate certain residual risk fac-
tors. There is a risk of the following injuries in con-
nection with the required operation of the machine:
• m WARNING! Danger of injury!
of ngers and hands by contact with the blade
shaft at uncovered areas when changing tools.
These can also be crushed by opening the guard.
• Eye injuries
• on the infeed and discharge opening by
dangerous recoil
• Danger from current if the electric cables have not
been connected correctly.
• harmful wood duct may be generated if operated
without an extractor or chip bag.
• by catapulted parts
• Metal parts in the workpiece can blunt or destroy
the blades.
• Lung damage if no suitable protective dust mask
is used.
m WARNING! Hearing damage!
A longer stay in the immediate vicinity of the running
unit may cause hearing damage.
Wear ear protectors!
Despite the observance of the operating instructions
there still may be some hidden residual risks.
Emergency procedure
Conduct a rst-aid procedure adequate to the
injury and summon qualied medical attendance as
quickly as possible. Protect the injured person from
further harm and calm them down. For the sake of
eventual accident, in accordance with DIN 13164, a
workplace has to be tted with a rst-aid kit. It is es-
sential to replace any used material in the rst-aid kit
immediately after it has been used. If you seek help,
state the following pieces of information:
1. Accident site
2. Accident type
3. Number of injured persons
4. Injury type(s)
6. Technical data
AC motor: 230-240V ~
50 Hz
Power P: 1500 W
Protection type: IP20
Max. workpiece width: 204 mm
Max. workpiece height at
thickness opening: 120 mm
Surfacing plane table: 370 x 212 mm
Thicknessing table: 270 x 204 mm
Thicknessing feeding speed: 6 m/min
Idle speed of cutter block: 9000 min
-1
Max. planing cross-cutting depth: 2 mm
Max. thicknessing cross-cutting depth: 2 mm
Max. angle of the parallel stop: 45°
Sawdust extractor: Ø 100 mm
Weight: 27 kg
Sound
Sound values were measured in accordance with
EN 61029.
Sound pressure level L
pA
92,9 dB(A)
Uncertainty K
pA
3 dB
Sound power level L
WA
105,9 dB(A)
Uncertainty K
WA
3 dB
