42
Dimension: 140mm x 215mm
Specifications
• Design and specifications are subject to change without notice.
MODEL 21FL94
Receiving System NTSC
Stereo Broadcast MTS/SAP
Reception Channels
AIR VHF 2-13 ch
UHF 14-69 ch
CATV 1-125 ch
Channel Tuning 181-channel Reception PLL tuning system
Antenna Input Impedance VHF/UHF 75 ohm Unbalanced
Screen Size 21˝ Diagonally Measured
(Visible Area) (50.8 cm)
Terminals Audio/Video input x 2 (Front x 1, Rear x 1),
COMPONENT-IN x 1 (Rear), Audio Output x 1 (Rear)
Sound Output 4 W (RMS) x 2
Power Source AC 110-220 V, 50/60 Hz
Power Consumption 90 W
Dimensions 23
25
/64˝ x 18
33
/64˝ x 19
1
/64˝
(W) x (H) x (D) [594 mm x 470 mm x 485 mm]
Weight (approx.) 56.2 lbs. (25.5 kg)
21FL94_42-44_EN 19/3/04, 11:53 am42
