PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
LC-24LE170I
CONTENTS
LED BACKLIGHT TV
LC-24LE170I
MODEL
[1] PRINTED WIRING BOARD ASSEMBLIES
[2] LCD PANEL
[3] MAIN/POWER UNIT
[4] LED/IR UNIT
[5] CABINET AND MECHANICAL PARTS
[6] LCD PANEL
[7] SUPPLIED ACCESORIES
[8] PACKING PARTS (NOT REPLACEMENT)
[9] EXPLODE VIEW
