Chapter 2
BEFORE USING THE MACHINE
This chapter contains basic information that should be read before using the machine.
PART NAMES AND FUNCTIONS
USB 2.0 port
Connect to your computer to this port to use the
printer and scanner functions.
Charger cleaner
Use to clean the transfer charger.
Glass cleaner
Use to clean the original scanning glass.
Document glass
Place an original that you wish to scan face down
here. (p.29)
Handles
Use to move the machine.
Power switch
Press to turn the machine power on and off.
Centre tray
Copies and printed pages are output to this tray.
Top tray (when the job separator tray kit is
installed)
Received faxes (when the fax option is installed) and
print jobs are delivered to this tray.
Operation panel
Contains operation keys and indicator lights.
Front cover
Open to remove paper misfeeds or replace the toner
cartridge.
Tray 1
Tray 1 can hold approximately 250 sheets of copy
paper (80
g /m
2
(20 lbs.)).
Tray 2
Tray 2 can hold approximately 250 sheets of copy
paper (80
g /m
2
(20 lbs.)).
11
9
8
7
10
4
6
5
3
17 18
14
15
16
5
13
1
2
12
1
2
3
4
5
6
7
8
9
10
11
12
