Operating Instructions
LMS1xx Laser Measurement Sensors
Electrical installation
8012471/ZN27/2017-06-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 65
Chapter 6
6 Electrical installation
Only authorized personnel are allowed to perform the electrical installation work.
Do not open the housing of the device.
Only on LMS10x/LMS12x/LMS173 (indoor variants), remove temporarily the system
connector on the bottom of the device for connecting cable leads to the terminal blocks.
Observe the current safety regulations when working on electrical systems.
Switch the entire machine/system offline!
The machine/system could inadvertently start up while you are connecting the device.
Ensure that the entire machine/system is disconnected during the electrical
installation.
6.1 Overview of the installation steps
Wire switching outputs (application-dependent).
Temporarily connect PC (configuration).
Wire data interface for operation.
Connect the supply voltage to the LMS1xx
