SICK TiM55 Series User Manual

10 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/TiM5xx
Please note: This documentation may contain further technical data.
10.1
Features
Variant TiM55x/TiM56x/TiM57x/TiM58x
Measurement
principle
Type-dependent: HDDM or
HDDM+ (improved behavior for edge hits)
Application Outdoor
Light source TiM55x: Infrared (wavelength 850 nm, max. pulse power 880 mW, max.
pulse width 5 ns, pulse frequency 550 kHz)
TiM56x/TiM57x/TiM58x: Infrared (wavelength 850 nm, max. pulse power
880 mW, max. pulse width 5 ns, pulse frequency 1,500 kHz)
Laser class 1 (IEC 60825-1:2014, EN 60825-1:2014)
Complies with 21 CFR 1040.10 and 1040.11 except for the listed toleran‐
ces in the document “Laser Notice No. 50” of June 24, 2007.
Aperture angle 270° (horizontal)
Scanning fre‐
quency
15 Hz
Angular resolu‐
tion
TiM55x: 1°
TiM56x/TiM57x/TiM58x: 0.33°
Working range TiM55x/TiM56x: 0.05 m ... 10 m
TiM57x/TiM58x: 0.05 m ... 25 m
Scanning range
with 10% radi‐
ance factor
8 m (typical)
1
1
at ambient temperature < -15 °C: 7.5 m (typical)
TECHNICAL DATA 10
8025144//2021-07-21 | SICK O P E R A T I N G I N S T R U C T I O N S | TiM55x/56x/57x/58x
37
Subject to change without notice
