Administration
A31003-S2000-M102-3-76A9, 08/07/2009
3-8 Asterisk - OpenStage Family, Administration Manual
administration.fm
LAN Settings
3.2.2.1 Automatic VLAN discovery using DHCP
To automatically discover a VLAN ID using DHCP, the phone must be configured as DHCP en-
abled, and VLAN discovery mode must be set to "DHCP". This is the default configuration.
The DHCP server must be configured to supply the Vendor Unique Option in the correct Sie-
mens VLAN over DHCP format. If a phone configured for VLAN discovery by DHCP fails to dis-
cover its VLAN, it will proceed to configure itself from the DHCP within the non-tagged LAN.
Under these circumstances, network routing may probably not be correct.
Administration via WBM
Network > IP configuration
First, click on change mode. Afterwards, the IP configuration mode dialog opens.
Network > IP configuration > change mode
To enable VLAN discovery by DHCP, select DHCP used in the Discovery mode menu. After-
wards, click Submit.
