3.3.26 Read_AS-i_Slave_I/O
Purpose
With this call, the I/O configuration of an AS-i slave can be read out directly over
the AS-i cable. The call is intended for diagnostic purposes and is not required in
the normal master mode.
Structure of the Job Data in the Send Buffer
Byte Meaning
0 Command number: 18
1 Slave address
Structure of the Response Data in the Receive Buffer
Byte Meaning
Bit 7 Bit 4 Bit 3 Bit 0
0 reserved I/O configuration
