AS-Interface Protocol Implementation Conformance Statement (PICS)
140
DP/AS-Interface Link 20E
Release 11/2002
C79000-G8976-C138–04
Table A-2 , continued
No. Comment / Function implemented by / see
Section
M1eFunction or Call on the Host Interface
(symbolic representation)
8 Status =
Set_Permanent_Configuration(Addr,
Config)
X see Section 3.3
9 Status, Config =
Get_Permanent_Configuration(Addr)
X see Section 3.3
10 Status = Store_Actual_Configuration() X By pressing the SET button; also using a
command (see Section 3.3)
11 Status, Config =
Read_Actual_Configuration(Addr)
X see Section 3.3
12 Status = Set_LPS(List31) X see Section 3.3
13 Status, List31 = Get_LPS() X see Section 3.3
14 Status, List31 = Get_LAS() X see Section 3.3
15 Status, List32 = Get_LDS() X see Section 3.3
16.0 Status = Get_Flags() X see Section 3.3
16.1 Status, Flag = Get_Flag_Config_OK() X see Section 3.3
16.2 Status, Flag = Get_Flag_LDS.0() X see Section 3.3
16.3 Status, Flag =
Get_Flag_Auto_Address_Assign()
X see Section 3.3
16.4 Status, Flag =
Get_Flag_Auto_Prog_Available()
X see Section 3.3
16.5 Status, Flag =
Get_Flag_Configuration_Active()
X see Section 3.3
16.6 Status, Flag =
Get_Flag_Normal_Operation_Active()
X see Section 3.3
16.7 Status, Flag = Get_Flag_APF() X see Section 3.3
16.8 Status, Flag = Get_Flag_Offline_Ready() X see Section 3.3
16.9 Status, Flag = Get_Flag_Periphery_OK() X see Section 3.3
17 Status = Set_Operation_Mode(Mode) X By pressing the SET button;
also with a command (see Section 3.3)
18 Status = Set_Offline_Mode(Mode) X see Section 3.3
19 Status = Activate_Data_Exchange(Mode) – not implemented
20 Status = Change_Slave_Address(Addr1,
Addr2)
X see Section 3.3
21.1 Status = Set_Auto_Address_Enable X see Section 3.3
21.2 Status = Get_Auto_Address_Enable X see Section 3.3
22.1 Status, Resp =
Cmd_Reset_ASI_Slave(Addr, RESET)
X see Section 3.3
To Next Page
