Fuses
Three control fuses (2 primary, 1 secondary) located in the control wireway section of the drive
enclosure, protect the 500 VA transformer.
Note
Selection Option Code K79
With the selection of Option K79 (Auxiliary and Control Voltage Supply) is selected, there is
no Auxiliary Transformer installed. The customer supplies voltage to the drive.
3.1.4.2 Control Door Cabinet Components
Multilanguage Keypad and Operator Panel
Depending on configuration the drive is equipped with one of the following panels:
● Multi-Language Keypad
● SIMATIC HMI KTP700 operator panel
The panels are located on the front of the drive control cabinet.
Multi-Language Keypad
Multi-Language Keypad and Display Interface
Description
3.1 Cabinet Details
SINAMICS PERFECT HARMONY GH180 6SR41 manufactured in NMA Nuernberg, Germany
34 Operating Instructions Rev.201706301306
