Siemens LOGO! 230 RC User Manual

71
LOGO! manual
EWA 4NEB 712 6006-02
4.2 Setting the time (LOGO! 230 RC)
You can set the time:
S In parameterization mode
S In programming mode
Setting the time in parameterization mode:
1. Switch to parameterization mode:
ESC and OK simultaneously
2. Select ’Set Clock’, and press OK
Set Clock
Day =_Mo
The cursor is positioned before the day of
the week
Time=09:06
3. Select the day of the week: or
4. Move the cursor to the next position: or
5. Change the value at this position: or
6. Set the clock to the correct time. Repeat steps 4 and 5
7. Conclude your input: OK
Setting the time in programming mode:
1. Switch to programming mode:
, and OK
2. Select ’Program..’, and press OK
3. Select (using or ) ’Set Clock’, and press OK
Now you can set the day of the week and the time, as described above (as
of step 3).
Parameterizing LOGO!

Siemens LOGO! 230 RC Specifications

General

Inputs	8 digital inputs
Outputs	4 relay outputs
Input voltage type	AC
Width	72 mm
Height	90 mm
Depth	55 mm
Number of analog inputs	0
Number of analog outputs	0
Operating temperature	0 °C to 55 °C
Storage temperature	-40 °C to 70 °C
Protection class	IP20
Digital inputs according to EN 61131-2	Type 1
Weight	approx. 210 g
Program Memory	400 function blocks
Dimensions	72 mm x 90 mm x 55 mm
