Siemens RDG20 KN Series User Manual

Technical data
7
182 | 186
A6V11545892_en--_e
Standards and directives
Environmental compatibility
The product environmental declaration (
RDG200KN: A5W00085404A
*
,
RDG260KN: A5W00116569A
*
,
RDG200KN/BK: A5W00242785A
*
,
RDG260KN/BK: A5W00242797A
*
,
RDG204KN: A5W00242787A
*
,
RDG264KN: A5W00242790A
*
,
RDG200T: A5W00304666A
*
,
RDG260T: A5W00304667A
*
) contains data on
environmentally compatible product design and
assessments (RoHS compliance, materials
composition, packaging, environmental benefit,
disposal).
General
Connection terminals
Solid wires or stranded wires with wire-end sleeves
1 x 0.4…2.5 mm
2
or 2 x 0.4…1.5 mm
2
Minimal wiring cross section on
L, N, Q1, Q2, Q3, Y1, Y2, Y3, Y4
Min. 1.5 mm
2
Maximal wiring cross section on
L, N, Q1, Q2, Q3, Y1, Y2, Y3, Y4
Max. 2.5 mm
2
Housing front color
RAL 9016 white
RAL 9011 black (RDG2..KN/BK)
Weight without/with packaging
RDG200KN / RDG200KN/BK / RDG200T
RDG204KN
RDG260KN / RDG260KN/BK / RDG260T
RDG264KN
266 g/336 g
270.3 g/345.9 g
242 g/311 g
269.5 g/324.6 g
Reference documentation (RDG2..KN)
Handbook for Home and Building Control - Basic
Principles
(EN:https://my.knx.org/shop/product?language=en&pr
oduct_type_category=books&product_type=handbook
DE:
https://my.knx.org/shop/product?language=de&produc
t_type_category=books&product_type=handbook)
Synco
TM
(RDG2..KN)
CE1P3127 Communication via KNX bus for Synco
700, 900 and RXB/RXL
Basic documentation
Desigo (RDG2..KN)
CM1Y9775 Desigo RXB integration – S-Mode
CM1Y9776 Desigo RXB/RXL integration – individual
addressing
CM1Y9777 Third-party integration
CM1Y9778 Synco integration
CM1Y9779 Working with ETS
*) The documents can be downloaded from https://hit.sbt.siemens.com.
