Upkeep and maintenance
7.4 Restoring the factory settings
SCALANCE XR-500
80 Operating Instructions, 05/2017, A5E03275845-11
Follow the steps below to load new firmware using TFTP:
1. Turn off the power to the device.
2. Now press the "SELECT/SET" button and reconnect the power to the device while
holding down the button.
3. Hold down the button until the red fault LED "F" starts to flash after approximately 30
seconds.
4. Now release the button. The bootloader of the device waits in this status for a new
firmware file that you can download by TFTP.
5. Connect a PC to the out-band interface of the device via an Ethernet cable.
6. Assign an IP address to the device using DHCP or the Primary Setup Tool.
7. Open a Windows command prompt and change to the directory where the file with the
new firmware is located and then execute the following command :
tftp -i <IP address> put <firmware file>
Note
You can enable TFTP in Microsoft Windows as follows:
"Control Panel" > "Programs and Features" > "Turn Windows feature
s on or off" > "TFTP
8. Once the firmware has been transferred completely to the device and validated, there is
an automatic restart on the device. This may take several minutes.
Restoring the factory settings
If you reset, all the settings you have made will be overwritten by factory defaults.
An inadvertent reset can cause disturbances and failures in the configured network.
