Technical data
8.2 Technical specifications of the SCALANCE XR526-8C
SCALANCE XR-500
86 Operating Instructions, 05/2017, A5E03275845-11
8.2
Technical specifications of the SCALANCE XR526-8C
The following technical specifications apply to the SCALANCE XR526-8C.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
1)
Quantity
24
Connector
RJ-45 jack
Transmission speed
10 / 100/ 1000 Mbps
Slots for SFP transceivers
Quantity
8
Connector
SFP transceiver
Transmission speed
100 / 1000 Mbps
Slots for SFP transceivers (SFP+)
Quantity
2
Connector
SFP+ transceiver
Transmission speed
1000 Mbps – 10 Gbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Out-of-band interface
Quantity
1
Connector
RJ-45 jack
Signaling contact
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Connection to power supply
2 x 24 VDC
Design
Terminal block, 4 terminals
Rated voltage
24 VDC
Voltage range
19.2 VDC - 28.8 VDC
Fusing
3.15 A / 125 V
Current consumption 1.5 A
Effective power loss 36 W
Cable cross-section
• Minimum
• Maximum
• 0.75 mm
2
(18 AWG)
• 2.5 mm
2
(12 AWG)
Properties
Implemented redundantly
1 x 100 to 240 VAC Design IEC plug C14 with switch,
2-pin
Rated voltage
100 V to 240 V AC
Voltage range
90 to 264 VAC
Frequency
60 Hz to 50 Hz
Frequency range
47 Hz to 63 Hz
Fusing
3.15 A / 250 V
