Technical data
8
8.1
Technical specifications of the SCALANCE XR524-8C
The following technical specifications apply to the SCALANCE XR524-8C.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
1)
Quantity 24
Connector RJ-45 jack
Transmission speed 10 / 100/ 1000 Mbps
Slots for SFP transceivers
Quantity
8
Connector
SFP transceiver
Transmission speed
100 / 1000 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Out-of-band interface
Quantity
1
Connector
RJ-45 jack
Signaling contact
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Connection to power supply
2 x 24 VDC
Design
Terminal block, 4 terminals
Rated voltage
24 VDC
Voltage range
19.2 VDC - 28.8 VDC
Fusing
3.15 A / 125 V
Current consumption
1 A
Effective power loss
24 W
Cable cross-section
• Minimum
• Maximum
• 0.75 mm
2
(18 AWG)
• 2.5 mm
2
(12 AWG)
Properties
Implemented redundantly
1 x 100 to 240 VAC Design IEC plug C14 with switch,
2-pin
Rated voltage
100 / 240 VAC
Voltage range
90 to 264 VAC
Frequency
60 Hz / 50 Hz
