8.2 Technical specifications of the SCALANCE XR526-8C
SCALANCE XR-500
88 Operating Instructions, 05/2017, A5E03275845-11
Technical specifications
Installation options
• 19" rack mounting
• Desktop operation
• Four-point mounting
Design of the mounting bracket for use on ships
Dimensions without brackets for
19" rack mounting (W x H x D)
43.6 x 43.6 x 18.3 mm (1 height unit)
Plate thickness
1.5 mm
Inner bending radii
1.5 mm
Surface of the housing
Stainless steel X6CR17
Mean time between failure (MTBF)
• Basic device without pluggable
transceiver
• at 40 °C ambient temperature
2 x 24 VDC
> 18.61 years
1 x 100 to 240 VAC
> 10.25 years
2 x 100 to 240 VAC > 13.22 years
1)
When working with electrical connectors, make sure that the isolation between the ports is
maintained, see "Isolation between ports".
2)
Depending on which pluggable transceiver you use, the maximum ambient temperature
can change, see section "Permitted ambient temperature (Page 19)".
Note
ISO tolerance and punching burr
For dimensions without tolerance details, the general tolerances "medium" acc. to DIN ISO
2768 apply. No punching burrs are permitted.
Isolation between ports
SCALANCE XR526-8C has four port groups:
● Group 1: P1 - P4 and P13 - P16
● Group 2: P5 - P8 and P17 - P20
● Group 3: P9 - P10 and P21 - P22
● Group 4: P11 - P12 and P23 - P24
The requirements of the isolation voltage for Environment A (IEEE 802.3) are met between
ports of the same group, in other words, the electrical isolation of the ports is designed for
500 Vrms (1 minute). Example: between P1 and P15
The requirements of the isolation voltage for Environment B (IEEE 802.3) are met between
ports of different groups, in other words, the electrical isolation of the ports is designed for
1500 Vrms (1 minute). Example: between P6 and P23
