15 / 44
Siemens Application Guide «Fire Mode» CM1A5192en_01
Building Technologies Application Examples 23.10.2007
4.1.3 Parameter setting
Start with quick commissioning according the commissioning guide
CM1G5192. It is very important to enter the right motor data!
Par. Nr. Value Parameter function Function selection
P0003 3 User access level 3 Expert access
P0702(0) 26 Function of DIN2 in Auto mode ESM
P0702(1) 26 Function of DIN2 in Hand mode ESM
P1271(0)
Activation of ESM control word press▼ once;
will appear and ESM
control word is acti-
vated
For further information please see also Chapter 5 – Commissioning Wizard for
Essential Service Mode.
4.1.4 Remarks
• The hand mode will be disabled automatically when ESM is active.
• The information “drive fault” and “drive running” is still available on the 2 relay
outputs.
On demand the information “ESM active” can be configured to a relay output.
