Siemens SIMATIC CPU 1515SP PC2 F User Manual

Technical specifications
12.7 Module data
CPU 1515SP PC2 (F/T/TF)
118 Operating Instructions, 09/2018, A5E42603425-AA
Article number
6ES7677-2WB42-0GB0
Memory
Type of memory
DDR3L
Main memory
8 GB RAM
CFast memory card
Yes; 30 GB flash memory
SIMATIC memory card required
No
Flash Disk
30 GB
Work memory
• integrated (for program)
1.5 Mbyte
• integrated (for data)
5 Mbyte
• integrated (for CPU function library of CPU
Runtime)
10 Mbyte
Load memory
• integrated (on PC mass storage)
320 Mbyte
Backup
• with UPS
Yes; all memory areas declared retentive
• with non-volatile memory
Yes
Hardware configuration
Integrated power supply
Yes
Number of DP masters
• Via CM
1
Rack
• Modules per rack, max.
64; CPU 1515SP PC + 64 modules + server
module
• Number of lines, max.
1
Time of day
Clock
• Type
Hardware clock
• Backup time
6 wk; At 40 °C ambient temperature, typically
• Deviation per day, max.
10 s; Typ.: 2 s
Interfaces
Number of industrial Ethernet interfaces
2
Number of PROFINET interfaces 1
Number of PROFIBUS interfaces
1
Number of RS 485 interfaces 1; Via CM DP module
Number of USB interfaces
4; 2x USB 2.0, 2x USB 3.0 on front side
Number of SD card slots 1
Video interfaces
• Graphics interface
1x DisplayPort
