Product overview
4.4 Components
CPU 1515SP PC2 (F/T/TF)
22 Operating Instructions, 09/2018, A5E42603425-AA
4.4
Components
Components of the CPU 1515SP PC2
The following table provides an overview of the components of the CPU 1515SP PC2:
Table 4- 1 Components of the CPU 1515SP PC2
Component
Function
Figure
Mounting rail in accordance
with EN 60715
The mounting rail is the rack for the
CPU 1515SP PC2.
CPU 1515SP PC2 CPU with strain relief and white refer-
ence labels
