Operating a project
6.9 Closing the project
Comfort Panels
182 Operating Instructions, 07/2017, A5E36770603-AB
If an infotext is configured for an operating element, the infotext is displayed on the HMI
device as follows:
● With touch devices, the <Help> key is shown in the screen keyboard.
● With key HMI devices, the LED lights the <HELP> key.
Operating element with the configured infotext is selected.
Proceed as follows:
1. Press the <HELP> key.
The infotext for the operating element is displayed.
2. Use the cursor keys to scroll as needed.
Note
Switching between displayed infotext
The configuration engineer can configure infotex
t for an I/O field and the associated
screen. You can switch between two infotexts by touching the infotext window.
3. Close the window with the infotext.
Depending on your configuration, infotext can also be called by means of a configured
operating element.
Refer to your system documentation to find any additional information on this topic.
Closing the project
Procedure
Proceed as follows:
1. Use the corresponding operating element object to close the project.
Wait for the Loader to open after you have closed the project.
2. Switch off power to the HMI device.
