Configuration
4.9 Data points
CP 1243-1
72 Operating Instructions, 12/2016, C79000-G8976-C365-02
Supported data point types of the CP
Table 4- 1 Supported data point types and compatible S7 data types
Format (memory re-
quirements)
Data point type
S7 data types
Address area
Bit
Digital input
Bool
I, Q, M, DB
Digital output Bool Q, M, DB
Byte
Digital input
Byte, USInt
I, Q, M, DB
Digital output
Byte, USInt
Q, M, DB
Integer with sign (16 bits)
Analog input
Int
I, Q, M, DB
Analog output
Int
Q, M, DB
Counter (16 bits)
Counter input
Word, UInt
I, Q, M, DB
Integer with sign (32 bits)
Analog input
DInt
Q, M, DB
Analog output
DInt
Q, M, DB
Counter (32 bits)
Counter input
UDInt, DWord
I, Q, M, DB
Floating-point number
with sign (32 bits)
Analog input
Real
Q, M, DB
Analog output
Real
Q, M, DB
Floating-point number
with sign (64 bits)
Analog input
LReal
Q, M, DB
Analog output
LReal
Q, M, DB
Block of data
(1 .. 64 bytes)
Data
ARRAY
1)
DB
Data
ARRAY
1)
DB
1)
For the possible formats of the ARRAY data type, refer to the following section.
Block of data (ARRAY)
With the ARRAY data type, contiguous memory areas up to a size of 64 bytes can be
transferred. The following S7 data types are compatible components of ARRAY:
● Byte, USInt (total of up to 64 per data block)
● Int, UInt, Word (total of up to 32 per data block)
● DInt, UDInt, DWord (total of up to 16 per data block)
If the array is modified later, the data point must be recreated.
Time stamp in UTC format
Time stamps are transferred in UTC format (48 bits) and contain the time difference in
milliseconds since 01.01.1970.
4.9.4
Status IDs of data points
Status IDs of data points
Along with the value of a data point, status identifiers of the data point are transferred in
every frame. They can be evaluated by the communications partner.
