Diagnostics and upkeep
5.4 SNMP
CP 1243-1
94 Operating Instructions, 12/2016, C79000-G8976-C365-02
8. Click on the icon next to the "PG/PC interface" drop-down list.
The "Establish remote connection via telecontrol" dialog box opens.
9. Make the necessary entries in this dialog (see below) and click on "Connect".
Information in the "Establish remote connection via telecontrol" dialog.
In this dialog, enter the data previously configured in STEP 7 under the following headings:
●
Telecontrol server / TeleService gateway...
Selection whether the TeleService switching station is located on the PC of the
engineering station or in the network or can be reached via the Internet.
A TeleService gateway cannot be used as a switching station only the telecontrol server.
– Enter the address of the telecontrol server.
IP address or name and port number of the telecontrol server that can be resolved by
DNS
– Own server password
Enter the telecontrol password to authenticate the CP with the telecontrol server
The telecontrol password for the CP is configured under "CP identification" of the
security settings, see also the section CP identification (Page 48).
●
– Teleservice user name and password
Here, enter the data for the TeleService user that you configured in STEP 7 in the
global Security settings, see also section Configuration of the TeleService access
(Page 63).
Terminate online connection
On completion of the online session, terminate the online connection again using the
"Disconnect" button.
SNMP
SNMP (Simple Network Management Protocol)
SNMP is a protocol for management and diagnostics of networks and nodes in the network.
To transmit data, SNMP uses the connectionless UDP protocol.
The information on the properties of SNMP-compliant devices is entered in MIB files (MIB =
Management Information Base).
