Siemens SIMATIC RF1040R User Manual

Programming
6.2 Programming via USB interface
SIMATIC RF1000
Operating Instructions, 11/2019, C79000-G8976-C432-06
23
Table 6- 1 Description of the parameters
Parameter
Description
brp_open_usb_session
The parameter opens a connection to the reader via the USB interface.
Handle Session key initialized by this function. The session key is valid as soon as
"BRP_OK" is returned.
ProductID
0x00
Return value
• BRP_OK
• BRP_ERR_BUSY
• BRP_ERR_GENERAL_IO
• BRP_ERR_BUFFER_OVERFLOW
• BRP_ERR_NO_MORE_HANDLES
• BRP_ERR_INSUFFICIENT_MEM
You will find more information on return values in the section "Return val-
ues (Page 35)".
6.2.1.2 brp_set_bufsize
This function allows you to define the buffer size for the job and response telegrams. Note
that the buffer size is automatically set to the default value of 128 bytes after the restart.
Function call
int
brp_set_bufsize(
int * Handle,
int TotalBufsize,
int SendBufsize,
int RecvBufsize
);
Table 6- 2 Description of the parameters
Parameter
Description
brp_open_usb_session
The parameter opens a connection to the reader via the USB interface.
Handle
The session key returned by the function "brp_open_usb_session".
TotalBufsize Specifying the maximum size of the job and response telegram
• Default value: 128 bytes (data length 122 bytes)
• RF1060R: max. 512 bytes (data length 506 bytes)
• RF1040R/RF1070R: max. 1024 bytes (data length 1018 bytes)
SendBufsize Specifying the maximum size of the request telegram
• Default value: 128 bytes (data length 122 bytes)
• RF1060R: max. 512 bytes (data length 506 bytes)
• RF1040R/RF1070R: max. 1024 bytes (data length 1018 bytes)

Siemens SIMATIC RF1040R Specifications

General

Type	RFID Reader
Interface	Ethernet
Protection Class	IP65
Antenna Ports	4
Power Supply	24 V DC
Operating frequency	865-868 MHz
RF Standards	ISO 18000-6C
Read Range	Up to 6 meters
Communication Interface	Ethernet
Dimensions	50 mm x 50 mm x 25 mm
Frequency Range	865 to 868 MHz (EU), 902 to 928 MHz (US)
Operating Temperature	-25°C to +55°C
