Siemens SIMATIC RF1040R User Manual

Programming
6.3 Programming via the RS232 interface
SIMATIC RF1000
46 Operating Instructions, 11/2019, C79000-G8976-C432-06
6.3.2.10 Autoread_SetMode
Max. reader response time: 100 ms
Table 6- 42 Request telegram
Byte
Value
Description
0
0x0C
Without checksum
0x1C With checksum
1
0x05
DevCode
2 0x00 CmdCode
3
0x01
Parameter length (1 byte)
4
0x00
5 0xXX Autoread:
• Off (0x00)
• On, permanently (0x01)
• On, once (0x02)
6
0xXX
Optional checksum (when the value "0x1C" is set in byte 0)
Table 6- 43 Response telegram without errors
Byte
Value
Description
0
0x0C
Without checksum
0x1C
With checksum
1
0x05
DevCode
2
0x00
CmdCode
3 ... 4
0x00
Parameter length (0 bytes)
5
0xC4
Optional checksum (when the value "0x1C" is set in byte 0)
6.3.2.11 Autoread_GetMessage
Max. reader response time: 100 ms
Table 6- 44 Request telegram
Byte
Value
Description
0
0x0C
Without checksum
0x1C
With checksum
1
0x05
DevCode
2
0x01
CmdCode
3 ... 4
0x00
Parameter length (0 bytes)
5
0x4D
Optional checksum "BCC8" (when the value "0x1C" is set in byte 0)
