Programming
6.4 Status codes
SIMATIC RF1000
48 Operating Instructions, 11/2019, C79000-G8976-C432-06
6.4 Status codes
The following table contains a list of the status codes of the VHL command set divided up
into command groups.
Table 6- 47 General status codes
0x0101 0x01 NOTAG_ERR Transponder does not exist or no response.
This status code requires reselection of the
card with the function "vhl_select".
0x0102 0x02 CARD_NOT_SELECTED_ERR The function cannot be executed because
no transponder is selected.
0x0103 0x03 HF_ERR Communications problems with the tran-
0x0104 0x04 CONFIG_ERR The structure of the VHL file is invalid or the
0x0105 0x05 AUTH_ERR Authentication error. The keys in the VHL
file are invalid (MIFARE) or the stamp in the
reader is invalid (LEGIC cards).
0x0106 0x06 READ_ERR The communications sequence is success-
This value is currently not supported.
A transponder was recognized.
0x0109 0x09 INVALID_CARD_FAMILY_ERR The required transponder type does not
match the transponder family of the current-
ly selected transponder.
The function is not supported.
0x010C 0x0C VHL_HW_ERR Hardware problems during access (e.g. on
0x0501 0x01 NO_MESSAGE_ERR No valid card / no valid transponder recog-
0x0502 0x02 SCRIPT_RUNTIME_ERR Runtime error detected during script execu-
Syntax error in the script
"Autoread" function is switched off.
