Description
2.2 Connection options and supported transponders
SIMATIC RF1000
Operating Instructions, 11/2019, C79000-G8976-C432-06
9
2.2 Connection options and supported transponders
Depending on the interface protocol used, the readers can be used for various applications.
The following table provides an overview of the possible uses of the readers.
Table 2- 1 Possible uses
SIMATIC RF1060R
SIMATIC RF1040R/RF1070R
Interface/Protocol
USB
USB
RS232 / Freeport
application PM LOGON,
demo application
PM LOGON,
demo application
STEP 7 (TIA Portal)
Programming DLL for PC DLL for PC Ident pro-
file/
blocks
P2P
blocks
Connector SIMATIC Panel, PC SIMATIC Panel, PC RF170C e.g.
ET 200SP
Cable Included in the
scope of delivery
Included in the
scope of delivery
6GT2891-
4UH20
6GT2891-
2UH30
Supported transponders and protocols
The following table provides an overview of the transponders and protocols supported by the
readers.
Table 2- 2 Supported transponders
SIMATIC RF1040R
SIMATIC RF1060R
SIMATIC RF1070R
MDS D1xx, D3xx, E6xx
✓
✓
✓
MDS D2xx
✓
✓
1)
✓
MDS D4xx, D5xx
✓
✓
--
✓
: Reading the serial number as well as reading and writing the user memory area
1)
Only for read-only access
