8.2 4 /8 F-DI/4 F-DO DC24V/2A PROFIsafe Digital Electronic Module
ET 200pro Distributed I/O System - Fail-Safe Modules
92 Operating Instructions, 05/2007, A5E00394073-02
8.2.4 Parameters for the 4/8 F-DI/4 F-DO DC24V/2 A PROFIsafe Electronic Module
Parameters in STEP 7
The following table shows the parameters that can be set for the F-DI/F-DO module (see
also
"Configuration and Parameter Assignment" ).
Table 8-17 Parameters of the F-DI/DO Module
Parameters Range Default Type of
parameter
Range of
effectiveness
F-parameters:
F_destination_addre
ss
1 to 1022 Assigned by STEP 7 Static Module
F-monitoring time 10 to 10000 ms 150 ms Static Module
Module Parameters:
Behavior after
channel faults*
Passivate the entire
module/Passivate the
channel
Passivate the entire
module
Static Module
Module Parameter Inputs:
Input delay 0.5; 3; 15 ms 3 ms Static Module
Short-circuit test Cyclic/Disable Cyclic Static Module
Channel n, n+4 Enabled/disabled Enabled Static Channel
group
Evaluation of the
sensors
1oo2 evaluation/
1oo1 evaluation
1oo2 evaluation Static Channel
group
Type of sensor
interconnection
1-channel;
2-channel equivalent;
2-channel
nonequivalent
2-channel equivalent Static Channel
group
Behavior at
discrepancy
Provide last valid value;
Provide value 0
Provide last valid
value
Static Channel
group
Discrepancy time 10 to 30000 ms 10 ms Static Channel
group
Reintegration after
discrepancy error
Test of 0-signal not
required/Test of 0-
signal required
Test of 0-signal not
required
Static Channel
group
Module Parameter Outputs:
DO channel n Enabled/disabled Enabled Static Channel
Readback time 1 to 400 ms 1 ms Static Channel
Diagnostics: Wire
break
Enabled/disabled Disabled Static Channel
* This setting is only relevant when the S7 Distributed Safety V 5.4 or higher optional package is
installed.
