Technical data
10.1 Technical data of the DM-F Local and DM-F PROFIsafe fail-safe digital modules
94
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
Mounting
Snap-mounted onto 35 mm DIN rail or screw-mounted using additional push-in
lugs
Power consumption
DM-F Local:
• 24 V DC: 3 W
• 110 V to 240 V AC/DC: 9.5 VA/4.5 W
DM-F PROFIsafe:
• 24 V DC: 4 W
• 110 V to 240 V AC/DC: 11.0 VA/5.5 W
Protective separation according to
IEC 60947-1
Between relay enabling circuits/relay outputs and electronics
Rated insulation voltage U
i
300 V (at pollution degree 3)
Rated impulse withstand voltage U
imp
4 kV
Power loss ride-through time
110 V - 240 V AC/DC,
typ. 20 ms at
0.85 x U
s
, typ. 200 ms
at 230 V
24 V DC, typ. 20 ms at 0.8 x U
s
Relay outputs
• Quantity
2 monostable relay outputs
• Function • Common connection is internally disconnected in a fail-safe manner by a relay
enabling circuit
• Normally open contact, freely assignable to the control functions
Electrical service life of relay outputs
0.1 million switching cycles (AC-15, 230 V/3 A)
Relay enabling circuits
• Quantity
2 common switching-type, fail-safe relay enabling circuits
• Function
Fail-safe normally open contacts
• Prescribed short-circuit protection
for relay enabling circuits/relay
outputs
Fuse links operating class gL/gG 4 A (IEC 60947-5-1), separate for each relay
enabling circuit
• Rated uninterrupted current of
relay enabling circuits
5 A
• Rated switching capacity of relay
enabling circuits
AC-15
DC-13
3 A/24 V AC
4 A/24 V DC
3 A/120 V AC
0.55 A/60 V DC
1.5 A/230 V AC
0.22 A/125 V DC 0.11 A/250 V DC
• Electrical service life of relay
enabling circuits
0.1 million switching cycles (AC-15, 240 V/2 A)
• Switching rate of the relay enabling
circuits
2000/h
