SIMODRIVE 611A Installation and Start–Up Guide/IAA/–04.97 Edition
Troubleshooting
Table 8-1 Troubleshooting
Fault, user–
friendly interface
Fault, standard
interface
Possible fault cause
1 H1 RMS torque too high? ambient temp.40 _C?
2 H2 Actual value cable and shield correctly connected? Motor encoder
defective?
3 H1 Motor overloaded, RMS torque too high?
4 H2 Refer to F2
5 H1 Axis mechanically locked? RMS torque too high?
6 H1 Motor incorrectly connected? External moment of inertia too high?
RMS to high (mechanically locked)?
7 – Motor feeder interrupted, motor feeder, short–circuit/ground fault
(Vce monitoring stored up to POWER–ON)?
Fault cannot be removed → replace module
F – 5V level faulted ! replace module
