Page #83 background image
VS
07.94
1-83
Siemens AG 1997 All Rights reserved
SIMODRIVE 611A Installation and Start–Up Guide/IAA/–04.97 Edition
Short start–up, standard settings
The setting elements for the user–friendly interface are located on the parame-
ter board, for the standard interface, on the control (refer to Section 9 Appen-
dix). The tachometer adaptation, current normalization and current controller
gain parameters should be set for a standard start–up.
Tachometer adaptation for motors with tachometer
voltages 16.5 V at rated speed
Only for 1FT503VVAF71 and 1FT504VVAF71 motors
All three contacts, switch S1 (S4 for the 2nd axis standard interface) = ON
Further, an adjustment can be made using discrete resistors.
Current controller settings
The settings for the current limit and current controller gain Kp(I) can be taken
from the adaptation tables, Table 1-3 up to Table 1-9. If the required feed mo-
dule/motor combination cannot be found, the values can be determined using
the associated formulas.
Parameter board, switch S2
Control board, switch S2 (S5 for 2nd axis)
Note
The following setting values are valid for both control versions, as long as, in
individual cases, specific reference is not made to differences.
User–friendly– and
standard interface
User–friendly inter-
face
Standard interface
Feed modules (VS)
1 Short start–up, standard settings04.97
