1FK2 synchronous motors for SINAMICS S120
Configuration Manual, 06/2019, A5E46927724B AB
43
Motor components and options
Motors with DRIVE-CLiQ interface are designed to operate with the SINAMICS converter
system.
Signal transmission to the converter is performed digitally.
The motors have an electronic rating plate that simplifies commissioning and diagnostics.
The motor and encoder system are automatically identified and all motor parameters are
automatically set.
You will find further information in the relevant SINAMICS manual.
Damage to electrostatic sensitive devices
The contacts of the DRIVE-CLiQ interface have direct contact with components that can be
destroyed by electrostatic discharge (ESDS).
• Avoid touching the terminals directly with hands or tools. They may be electrostatically
charged and damage components.
The encoders are suitable for the Extended Safety Functions.
Table 4- 1 The 1FK2 can be supplied with the following encoders:
Absolute encoder, singleturn,
22 bit
Absolute encoder 22 bit +12 bit
multiturn
Description Absolute encoder 22 bit single-
turn
Absolute encoder 22 bit + 12 bit
multiturn
Identifier at the 14th digit of the
article number
S M
Operating voltage 24 V 24 V
Maximum current consumption 70 mA 70 mA
Resolution 4,194,304 = 22 bit 4,194,304 = 22 bit
Absolute position Yes, one revolution Yes, 4096 revolutions (12 bit)
Angular error ± 100 " ± 100 "
