Siemens SIMOTICS S-1FK2 Series User Manual

1FK2 synchronous motors for SINAMICS S120
Configuration Manual, 06/2019, A5E46927724B AB
49
Configuration
5
5.1
Configuring software
5.1.1
SIZER configuration tool
Overview
The SIZER calculation tool supports you in the technical dimensioning of the hardware and
firmware components required for a drive task.
SIZER supports the following configuration steps:
● Configuring the power supply
● Designing the motor and gearbox, including calculation of mechanical transmission
elements
● Configuring the drive components
● Compiling the required accessories
● Selection of the line-side and motor-side power options
The configuration process produces the following results:
● A parts list of components required (Export to Excel)
● Technical specifications of the system
● Characteristic curves
● Comments on system reactions
● Installation information of the drive and control components
● Energy considerations of the configured drive systems
You can find additional information that you can download in the Internet at SIZER
(https://support.industry.siemens.com/cs/document/54992004/sizer-for-siemens-
drives?dti=0&pnid=13434&lc=en-WW).
