Supplementary system components
6.5 CX32-2 controller extension
SIMOTION D4x5-2
124 Manual, 02/2012
6.5.5 RESET button
The RESET button is on the front of the device under the cover.
Function of the RESET button
The following reference contains information about the RESET button function:
●
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual.
6.5.6 Commissioning
Information on the commissioning in the following reference:
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual.
6.5.7 Technical data of the CX32-2
Memory for system data
Table 6- 28 Diagnostic buffer
Data SIMOTION CX32-2
Diagnostic buffer (protected against power
failure)
200 messages
The data for the CX32-2 is stored on the SIMOTION D4x5-2, which means no action has to
be taken on the CX32-2 when the module is replaced.
Dimensions and weights
Table 6- 29 Dimensions and weight of a SIMOTION CX32-2
Parameter SIMOTION CX32-2
Dimensions W x H x D [mm]
(max. expansion)
• Without fastening using spacers
• With fastening using spacers
• 25 x 380 x 230
• 25 x 380 x 270
Weight CX32-2 [g]
• Without packaging
• With packaging
• approx. 2600
• approx. 3150
