Supplementary system components
6.6 Terminal module TM31
SIMOTION D4x5-2
128 Manual, 02/2012
6.6 Terminal module TM31
Properties of the TM31
With the TM31 terminal module, the number of available digital inputs/digital outputs and the
number of analog input/analog outputs within a drive system can be expanded. The TM31 is
connected via DRIVE-CLiQ. It has two DRIVE-CLiQ interfaces for this.
The TM31 contains the following terminals:
Table 6- 36 Interface overview
Interface Number
Digital inputs 8
Bidirectional I/Os 4
Relay outputs with changeover contact 2
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
CAUTION
The 50 mm clearances above and below the components must be observed.
Additional references
You will find detailed information about the TM31 in the
●
SINAMICS S120 Control Units and Additional System Components
Manual
●
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual.
