7.4.8 Technical data
CBE30-2 technical data
Table 7-16 CBE30-2 technical data
Characteristic Value
Current requirement at 24 V DC 0.25 A
Approvals cULus (File No. E164110)
Marking for Australia C‑Tick mark
Storage and operation
Table 7-17
Ambient conditions for CBE30-2
Characteristic Value/Range Standard
Permissible ambient temperature
●
Storage
● Operation
-40° C... +70° C
0° C ... +55° C
Permissible relative humidity
(without condensation)
> 5 % to 95 % DIN EN 60721‑3‑3, Class 3K5
Degree of protection IP00 DIN EN 60529
Vibratory load DIN EN 60721‑3‑3, Class 3M6
Shock load DIN EN 60721‑3‑3, Class 3M4
Free fall DIN EN 60721‑3‑2, Class 2M1 and
2M2
Toppling DIN EN 60721‑3‑2, Class 2M1
Dimensions and weight
Characteristic Value
Dimensions (H x W x D) 25 x 95 x 143 mm
Weight 100 g
Supplementary system components
7.4 CBE30-2 Ethernet communication board
SIMOTION D4x5-2
Manual, 04/2014 115
