Pin Designation
1)
Signal type
2)
Notes
13 IN/OUT 7 B Digital input/output 7 (can be used as input of a measuring input
or output of an output cam)
14 M GND Ground
1)
IN/OUT: Bidirectional digital input/output; M: Electronic ground
2)
B = Bidirectional; GND = Reference potential (ground)
4.4.2
Using the digital inputs/outputs
Connecting sensors and actuators
Digital I/Os can be used to connect various sensors and actuators to the three 14-pin X122,
X132 and X142 front connectors.
The following types of digital I/Os are available:
● Digital inputs (DI)
● Bidirectional digital I/Os (DI/DO, IN/OUT)
Bidirectional digital I/Os can be configured individually as digital inputs or outputs.
Assignment of the I/Os to functions can be parameterized as required. Special functions (e.g.
input of measuring input and output for output cam) can also be assigned to the I/Os.
The digital I/Os on the X122 and X132 front connectors can be used by either SIMOTION or
SINAMICS (e.g. as enable signal for a drive).
The digital I/Os on the X142 front connector are permanently allocated to SIMOTION.
Table 4-11 Use of the digital I/Os
DI 0-7, DI 17, DI 18,
DI 20, DI 21 (X122,
X132)
DI/DO 8-15
(X122, X132)
IN/OUT 0-7
(X142)
Galvanic isolation Electrically isolated
(ground reference M1
or M2)
Non-isolated
(ground reference M)
Non-isolated
(ground reference M)
Use as:
● Freely addressable I/
Os for SIMOTION
Yes Yes Yes
● I/Os
that are assigned
to the drive
Yes Yes No
● Measuring inputs No Yes
(global and local
measuring inputs)
Yes
(global measuring
inputs)
● Inputs
for the external
zero mark
No Yes No
● Cam outputs No No Yes
Interfaces
4.4 Digital I/Os
SIMOTION D4x5-2
Manual, 04/2014 63
