The SIMOTION Kernel (SIMOTION D4x5‑2 firmware) and the software used to control the
drives (SINAMICS firmware) are contained on the CF card.
The CF card is used for
●
Backing up the technology packages and user data (programs, configuration data,
parameter assignments).
● Update (e.g. SIMOTION firmware update).
The licenses for the technology functions are linked to the serial number of the CF card. This
means the CF card can be inserted in a different SIMOTION D without having to change the
licenses.
The CF card is supplied in a bootable format with the latest SIMOTION Kernel and drive
software. Please note that a CF card with a D4x5 kernel/drive software cannot run on a D4x5‑2.
The same applies for the reverse situation.
If an error occurs, all LEDs flash yellow with 2 Hz. An entry is also made in the diagnostic buffer
and the D4x5‑2 does not start.
Licenses purchased for SIMOTION D can be used for both the D4x5 and D4x5‑2.
NOTICE
Damage to the CompactFlash card from electrical fields or electrostatic discharge
The CompactFlash card is an ESD-sensitive component.
De-energize the SIMOTION D4x5‑2 device before inserting or removing the CompactFlash
card. The SIMOTION D4x5‑2 is in a de-energized state when all the LEDs are off.
Comply with the ESD rules.
Additional information
For additional information about inserting, changing, writing and formatting the CF card, see
the
SIMOTION D4x5‑2
Commissioning and Hardware Installation Manual.
2.8.2 CompactFlash card
CF card
CF cards with different storage capacities are available for SIMOTION D4x5‑2.
At the time of writing, these were:
● 1-GB CF, order number 6AU1400-2PA23-0AA0
● 1-GB CF, order number 6AU1400-2PA22-0AA0
● 1-GB CF, order number 6AU1400-2PA21-0AA0
You will find detailed information on the compatibility relationships for the CF card, boot loader
version, SIMOTION D hardware and SIMOTION firmware version in the software compatibility
Description
2.8 CompactFlash card
SIMOTION D4x5-2
Manual, 04/2014 39
